Custom Medical Display Cover Glass | AR AG AF Touch Screen Panels

Custom Medical Display Cover Glass | AR AG AF Touch Screen Panels
Custom Medical Display Cover Glass | AR AG AF Touch Screen PanelsCustom Medical Display Cover Glass | AR AG AF Touch Screen PanelsCustom Medical Display Cover Glass | AR AG AF Touch Screen PanelsCustom Medical Display Cover Glass | AR AG AF Touch Screen PanelsCustom Medical Display Cover Glass | AR AG AF Touch Screen PanelsCustom Medical Display Cover Glass | AR AG AF Touch Screen Panels
Share
CategoriesIndustrial Touch Panel Glass
BrandFELIX GLASS optical glass Manufacturing base
Product SpecificationsFG-MED-GRADE-001
MaterialAluminosilicate glass; grade and strengthening route confirmed per drawing
ThicknessThickness and tolerance per drawing; dimensions and process reviewed together
SurfaceAR / AG / anti-fingerprint AF options; performance and tests agreed per order
ApplicationFront cover for medical displays and touch interfaces; device validation required
ShapeFlat cover panel; edge profile and printed bezel per drawing
Unit PriceUS $ 7.55-9.66 / piece
FOB portSHENZHEN SHANGHAI GUANGZHOU
Terms of PaymentL/C, D/A, D/P, Western Union
DownloadDownload pdfDownload pdfDownload pdfDownload pdfDownload pdf
Detail Information
Custom Medical Display Cover Glass

Send your drawing or sample requirement for a fast quotation. MOQ, lead time and coating options are confirmed within one business day.

Request a Quote

Custom Cover Glass for Medical Displays & Touch Interfaces

Felix Glass brings 19+ years of optical glass manufacturing and processing experience to custom cover panels for medical equipment OEMs. Specify the viewing area, printed bezel, mounting geometry and cleaning procedure so we can review a glass solution around your device design.

This product covers the front protective glass for medical monitors and operator touch interfaces, including display interfaces associated with CT, MRI and X-ray equipment. Radiation shielding, detector windows and complete display modules require separate specifications and quotations.

Send Your Medical Cover Glass Drawing

This listing supplies a display cover component. Antibacterial performance, device certification, radiation shielding and complete touch-module operation are not established by the glass material or an AR, AG or AF treatment.

Define the Cover Around Your Display

Start with the finished assembly: display resolution, viewing distance, ambient lighting, touch sensor, adhesive and enclosure. Mark the clear aperture separately from printed and bonded areas. Our guide to cover glass geometry and surface requirements helps organize these drawing notes.

Item Quotation starting point Confirm for your order
Product reference FG-MED-GRADE-001 Drawing number, revision and intended equipment interface.
Glass thickness Nominal thickness per approved drawing Selected thickness, tolerance, panel dimensions and material availability; feasibility depends on the complete size and process combination.
Material and strengthening Aluminosilicate glass; exact grade and strengthening route agreed per drawing Glass grade, edge condition, mechanical test and required stress profile. CS and DOL acceptance values belong in the agreed specification.
Coating options AR, AG and AF, selected by function Treated faces, spectral range, measurement angle, haze, appearance and cleaning durability.
Printing and edges Custom bezel, icons, openings and edge profile Artwork revision, color reference, registration tolerance, edge drawing and bonding exclusions.
Order quantity Current listing minimum: 5 pieces Prototype quantity and production forecast. Request a separate feasibility review for quantities below the listed minimum.
Pricing and timing Project quotation after drawing review Material, dimensions, coating, setup, quantity and required delivery date. Listing prices are not a quotation for every custom design.

Choose AR, AG and AF for Different Jobs

  • AR: request reflection and transmission requirements over the intended viewing conditions. Specify whether acceptance applies to the cover alone or the assembled display.
  • AG: evaluate a sample on the intended display before selecting haze and gloss. Include image detail, sparkle and appearance in your evaluation.
  • AF: define touch feel and wipe-clean requirements alongside durability. Include initial and post-test acceptance criteria in the RFQ.

Use our display coating selection guide to compare functions, and the comparison of glare control and fingerprint resistance when prioritizing surface treatments.

Make Cleaning Durability a Measurable Requirement

Send the disinfectant name, formulation or product reference, concentration, contact time, wiping material and expected cleaning frequency. Agree on a test sequence and the acceptable changes in appearance, print adhesion and coating performance. Review the finished panel, including its printed regions and exposed edges, against that sequence.

If antibacterial performance or biological evaluation is required, identify the intended use, contact conditions, test method and documentation needed before quotation. These requirements must be reviewed for the specific project; the application name alone is not an acceptance specification.

Strengthening, Printing and Inspection

Coordinate machining, edge finishing, strengthening, printing and coating as one approved manufacturing route. Review our strengthening and AF process overview and printed bezel and graphics guide before freezing the drawing.

Specify scratches, pits, chips and printing defects by inspection zone, lighting and viewing conditions. Agree which characteristics receive 100% inspection and which require batch or qualification tests. Request dimensional, optical, stress-profile and cleaning-durability records relevant to your acceptance plan.

If your drawing calls for 9H pencil hardness, identify the tested surface, method, load, conditioning and report requirement. Do not use that label as the acceptance criterion for impact performance.

Explore our glass fabrication and inspection capabilities, or use the optical material knowledge hub to organize a material comparison.

Relevant Medical Project and Product Options

For a related application, see the portable medical touch-device AF cover project. Use it as a discussion reference; qualification for a new device needs its own requirements and sample evaluation.

Questions Before Sampling

Does “medical grade” specify all requirements?

For your order, define the material, finished-part tests, documentation and intended use explicitly. Device qualification and assembly performance must be addressed in your project plan.

Can the cover be checked with our sensor and display?

Include the sensor stack, bonding method and display reference when requesting samples. Plan assembled-device checks for touch response, image appearance and cleaning compatibility.

What should we send for a quotation?

Send a dimensioned drawing and revision, thickness, material preference, clear aperture, artwork, coating requirements, cleaning procedure, inspection plan, quantities and target delivery date. Mark any unresolved requirements so they can be reviewed before sampling.

Discuss Your Medical Display Cover Project

Use the custom optics RFQ preparation checklist to prepare a complete technical inquiry. Ask for prototype and production pricing separately, with the assumptions and lead-time starting point identified.
